* Поставляется без объектива!
| Модель | PT-RS11K |
| Технология: | 3-Chip DLP |
| Разрешение: | 1400 ×1050 (SXGA+) |
| Яркость: | 12 000 Lm |
| Контраст: | 20,000:1 |
| Оптический трансфокатор (зум): | В зависимости от объектива (от 1,6х до 1,9х) |
| Проекционное отношение: | В зависимости от объектива |
| Фокусировка: | В зависимости от объектива |
| Сдвиг линз (моторизованный): | В зависимости от объектива |
| Источник света (Вт, срок работы): | Laser Diode, 20000 часов (Нормальный режим) |
| Энергопотребление (Вт): | 1200 Вт |
| Вход: | SDI IN 1 (BNC x2), HDMI x 1, DVI-D (DVI-D 24-pin ×1), RGB1 (BNC x 5), RGB2 (D-sub HD 15-pin x 1)3D SYNC1 (BNC x 1), SERIAL (D-sub 9 pin x 1), REMOTE 1 (M3 stereo mini jack × 1), REMOTE 2 (D-sub 9 pin × 1), DIGITAL LINK/LAN (RJ-45 x 1) |
| Выход: | 3D SYNC (BNC x 1), SERIAL (D-sub 9 pin x 1), REMOTE 1 (M3 stereo mini jack × 1) |
| Коррекция трапецеидальных искажений: | В зависимости от объектива |
| Шум (дБ): | 43 |
| Масса (кг): | 44 |
| Габариты (ШхВхГ мм): | 578 × 323.5 × 740 мм |
| Комплектация: | Panasonic проектор PT-RS11K (черный) |
| Пулт ДУ с батарейками | |
| Шнур питания | |
| Руководство по эксплуатации на CD | |
| Винт крепления объектива |
| PT-RS11K | |
| Power supply | 100–240 V AC, 50/60 Hz |
| Power consumption*1 | 1,200 W (1,280 VA) (0.3 W with Standby Mode set to Eco*2, 4 W with Standby Mode set to Normal); |
| Average power consumption: 800 W (Normal Mode), 680 W (Eco Mode), 620 W (Long Life 1 Mode), 590 W (Long Life 2 Mode), 550 W (Long Life 3 Mode) | |
| DLP™ chip | |
| Panel size | 24.1 mm (0.95?) diagonal (4:3 aspect ratio) |
| Display method | DLP™ chip x 3, DLP™ projection system |
| Pixels | 1,470,000 (1400 x 1050) x 3, total of 4,410,000 pixels |
| Refresh rate | 120 Hz*3 |
| Lens | Optional powered zoom and fixed-focus lenses |
| Light source | Laser diode (Class 1), Light source life*4: |
| 20,000 hours (Normal Mode) / 24,000 hours (Eco Mode) | |
| Screen size (diagonal) | 1.78–25.4 m (70–1,000?), 1.78–15.24 m (70–600?) |
| with the ET-D75LE8, 3.05–15.24 m (120–600?) | |
| with the ET-D75LE90, 4:3 aspect ratio | |
| Brightness*5 | 12,000 lm |
| Contrast*5 | 20,000:1 (Full On/Full Off, Dynamic Contrast Mode: 3) |
| Resolution | 1400 x 1050 pixels*6 |
| Supported RGB signal | XGA–WUXGA |
| Supported video signal | NTSC/PAL/SECAM, 480p/i, 720p, 1080p/i |
| Optical axis shift*7 | |
| (from center of screen) | |
| Vertical | ±50 % (±40 % with the ET-D75LE6, +71 % with the ET-D75LE90) (powered) |
| Horizontal | ±30 % (±20 % with the ET-D75LE6) (powered)*8 |
| Keystone correction range*9 | Vertical: ±40° (±22° with ET-D75LE50, ±28° with ET-D75LE6, +5° with ET-D75LE90), horizontal: ±15° (0° with ET-D75LE90) |
| Keystone correction range with optional Upgrade Kit ET-UK20*9 | Vertical: ±45° (±40° with ET-D75LE10/ET-D75LE20, ±22° with ET-D75LE50, ±28° with ET-D75LE6, +5° with ET-D75LE90), horizontal: ±40° (±15° with ET-D75LE50/ET-D75LE6, 0° with ET-D75LE90) |
| Installation | Ceiling/floor, front /rear, free 360-degree installation |
| Cabinet materials | Molded plastic |
| Dimensions (W x H x D) | 578 x 270 x 725 mm (22 3/4? x 10 5/8? x 28 17/32?) (optional lens, legs and lens cover not included), 578 x 323.5 x 740 mm (22 3/4? x 12 23/32? x 29 1/8?) |
| (Including legs at shortest position and protruding parts) | |
| Weight*10 | Approx. 44.0 kg (97 lbs) (optional lens not included) |
| Operation noise*5 | 43 dB |
| Operating environment | Operating temperature: 0–50 °C (32–122 °F)*11, operating humidity: 10–80 % (no condensation) |
| Applicable software | Logo Transfer Software, Multi Monitoring & Control Software, Early Warning Software, Geometry Manager Pro (ET-UK20 Upgrade Kit and ET-CUK10 Auto Screen Adjustment Kit) |
